Tungsten Carbide End Mill
Created with Pixso.

Blue Coated Tungsten Carbide End Mill , Carbide Milling Cutter For Machine Cutting

Blue Coated Tungsten Carbide End Mill , Carbide Milling Cutter For Machine Cutting

Brand Name: KTS
Model Number: CT-36
MOQ: 100PCS
Price: 1USD-20USD
Payment Terms: T/T, Western Union
Supply Ability: 10000PCS PER MONTH
Detail Information
Place of Origin:
zigong
Certification:
ISO9001-2008
MATERIAL:
SOLID CARBIDE
FLUTES:
4 FLUTES
COLOR:
BLUE
HRC:
65
Packaging Details:
PLASTIC TUBE
Highlight:

solid carbide end mill

,

carbide end mill cutter

Product Description

Blue Coated Carbide End Mill For Machine Cutting



Specification:



Name: END MILLS

Material: 100% raw material carbide
Metrial: Tungsten Carbide
Coating: HRC45° HRC50° HRC55° HRC60° HRC65°
Flute: 1Flute 2Flute 3Flute 4Flute 5Flute End Mills



DIAMETER: 4, 6, 8, 10, 12, 14, 16mm are available, the hot sale sizes mills are diameter less than 12mm.
CUSTOMIZE: OEM service is available.
SAMPLE SERVICE: Free samples but shipping fee







About Coatings:



Endmill Grade
Coating Name
Color
Hv
μm
Friction
The MaxºC
Application
HRC 45° coating
AlTiN
black
3300
0.6
0.7
850ºC
Suitable for General Steel
HRC 50° coating
AlTiN
black
3300
0.6
0.7
850ºC
Suitable for General Steel
HRC 55° coating
TiSiAlN
bronzed
3400
0.5
0.7
900ºC
General Steel,cast cast iron
HRC 60° coating
AlCrSiN
black
4000
0.4
0.35
1100ºC
High Hard Material, steel, cast iron, etc
HRC 65° coating
nACo 3 Blue
blue
4500
0.4
0.45
1200ºC
Titanium Alloy, High-temperature Alloy,material, etc
HSS
nACo 3 Blue
Other
4500
0.4
0.45
1200ºC
Stainless steel
Free Sample Test : Contact Us For Inquiry





Product Catalog:

Blue Coated Tungsten Carbide End Mill , Carbide Milling Cutter For Machine Cutting 0

Product Sizes:



D1 (Diameter of cut)
d (Shank Diameter)
L (Flute Length)
L1 (Overall Length)
1mm
4mm
3mm













50mm
1.5mm
4mm
4mm
2mm
4mm
6mm
2.5mm
4mm
8mm
3mm
3mm
8mm
3mm
4mm
8mm
3.5mm
4mm
11mm
4mm
4mm
11mm
1mm
6mm
3mm
1.5mm
6mm
4mm
2mm
6mm
6mm
2.5mm
6mm
8mm
3mm
6mm
8mm
3.5mm
6mm
11mm
4mm
6mm
11mm
4.5mm
6mm
13mm
5mm
5mm
13mm
5mm
6mm
13mm
6mm
6mm
15mm
7mm
8mm
20mm
8mm
8mm
20mm
9mm
10mm
25mm

75mm
10mm
10mm
25mm
12mm
12mm
30mm
14mm
14mm
45mm


100mm
16mm
16mm
45mm
18mm
18mm
45mm
20mm
20mm
45mm





Production Process:



Blue Coated Tungsten Carbide End Mill , Carbide Milling Cutter For Machine Cutting 1





Package & Shipping:

Blue Coated Tungsten Carbide End Mill , Carbide Milling Cutter For Machine Cutting 2





Our Advantages:

Suitable for finishing,can achieve the mirror effect.
coating increase surface gloss,and prolonging life.
100% quality guarantee (ISO9001)
Work material: carbide steel, alloy steel, cast iron, copper, mould steel,etc.
100% original tungsten, without recycle parts. Wc90%, Co10%, more cobalt will make end mills more crisp.
